Beams and Rods
Beams and rods are core structural components of kiln furniture systems. They provide stable, load-bearing support for kiln shelves and can also be used for direct setting of ceramic ware. Shouguan beams and rods are designed for demanding ceramic production, offering reliable performance at working temperatures up to 1350°C (depending on grade, kiln type, and firing conditions). Designed for high-temperature firing, with excellent thermal shock resistance and strong dimensional stability under demanding conditions. Helps reduce replacement frequency and long-term maintenance costs.
Rods
Silicon Carbide Rods
Inserted through the holes of support posts and arranged in parallel, silicon carbide (SiC) rods provide stable support for SiC shelves or direct setting of ceramic ware. The through-hole design helps reduce thermal mass and improve heat circulation, supporting more efficient heat transfer and potentially lowering energy consumption during firing.
Max Working Temperature
Up to 1350℃
Length
700-1600mm
(Customizable)
Diameter
15-20mm
(Customizable)
Aperture
8-12mm
(Customizable)
Corundum Rods
Corundum rods are alumina-based (Al₂O₃) support components used in post-and-beam kiln furniture setups, offering performance comparable to SiC rods under high-temperature firing conditions. With very low residue, they are ideal for ultra-clean firing requirements—often selected for bone china and other premium porcelain ware.
Max Working Temperature
Up to 1350℃
Length
700-1600mm
(Customizable)
Diameter
15-20mm
(Customizable)
Aperture
10-12mm
(Customizable)
Beams
Silicon Carbide / Corundum Beams
Silicon carbide and corundum (alumina) beams are key load-bearing components used together with rods to form a stable support grid within post-and-beam kiln furniure setups—distributing loads evenly and helping maintain dimensional stability through repeated firing cycles. Material selection depends on firing temperature, load conditions, and surface cleanliness requirements.
Max Working Temperature
Up to 1350℃
Length
900-1600mm
(Customizable)
Width
8-10mm
(Customizable)
Height
8-12mm
(Customizable)
